In the world of custom wiring harness manufacturing, materials are more than just components—they are the backbone of reliability, safety, and performance. At Celestix Industries, we don't just build to spec; we engineer wiring harnesses that exceed expectations, using only premium-grade materials aligned with the most rigorous international standards.

From automotive OEMs to aerospace, industrial automation, medical devices, and smart home appliances, material selection directly impacts performance, safety, and lifecycle. The right wire insulation or shielding can mean the difference between a robust, compliant harness and a costly field failure.

This comprehensive wire harness material guide helps engineers and procurement teams understand the critical elements in wiring harness construction and select the most reliable wiring harness materials for their applications.


Why Material Selection Matters

Every wire harness is only as strong as its weakest link. Material selection isn't just about choosing what works—it's about optimizing for longevity, compliance, and cost-efficiency. At Celestix, we engineer our harnesses with the customer application in mind, taking into account:

  • Voltage and current requirements

  • Thermal and environmental exposure

  • EMI/RFI sensitivity

  • Regulatory compliance (UL, RoHS, IATF, etc.)

  • Mechanical stress and movement

We Partner with You to Meet Your Specs

Whether you're building for automotive, industrial automation, medical devices, defense systems, or aerospace, we tailor the harness material selection to your exact operational needs, environmental demands, and compliance standards.


Core Wiring Harness Materials Used by Celestix

Celestix uses only high-grade, certified materials to ensure reliability and durability in any operating condition. This deep dive into materials in wiring harnesses outlines what goes into our high-performance solutions.

1. Conductor Materials

  • Copper wiring harness: Tinned or bare copper wire for unmatched conductivity.

  • Aluminum harness wiring: Lightweight option gaining popularity in EV applications.

  • Tinned copper harness: Offers corrosion resistance and long-term stability.

  • Stranded wire harness: Provides flexibility, ideal for dynamic assemblies.

  • Solid core harness wiring: Higher rigidity for static applications.

  • Conductor materials harness: Chosen based on thermal and electrical performance.

2. Insulation & Sheathing Materials

  • PVC harness insulation: Flame retardant, cost-efficient, ideal for general use.

  • Silicone harness sheathing: Extreme temperature resistance and flexibility.

  • TPE wiring harness material: Great flexibility and abrasion resistance.

  • LSZH harness insulation: Low-smoke, halogen-free option for fire-sensitive zones.

  • Heat-resistant harness insulation: Withstands thermal cycling in harsh conditions.

  • Harness sleeving materials: Braided, glass wool, and woven fabrics for abrasion and EMI protection.

  • Insulation wiring harness: Determines temperature and voltage resistance.

3. Connector & Terminal Materials

  • Plastic harness connectors: Lightweight, corrosion-resistant housings.

  • Metal terminal harness: Superior conductivity and durability.

  • Sealed harness connectors: Waterproof and dustproof options for rugged use.

  • Custom harness terminals: Designed to customer specs for an exact fit.

  • Connector materials harness: Sourced from trusted brands like TE, Molex, and Amphenol.

4. Wire Harness Components & Protection

  • Grommets, seals, mounting clips

  • Protective over-molding

  • EMI/RFI shielding layers (braided, foil, conductive tape)

  • Heat-shrink and cold-shrink tubing

  • Wire harness components that add structure, protection, and compliance


Certifications That Validate Our Materials

Celestix wiring harnesses meet or exceed global certification benchmarks. Our material suppliers and in-house processes are vetted to ensure every component aligns with relevant industry standards:

  • RoHS harness materials: Free from hazardous substances

  • UL-approved harness wiring: Compliant with global safety standards

  • BIS-compliant harness materials: Approved for the Indian market

  • ISO 9001:2015, IATF 16949:2016, UL, CE, REACH, IPC/WHMA-A-620, and more


Built to Perform Across Applications

Celestix manufactures and tests for the following industry-specific use cases:

  • Automotive harness materials: Flame-retardant, high-flex, vibration-resistant

  • EV wiring harness materials: Lightweight, high-voltage, thermally stable

  • Industrial harness materials: Heavy-duty sheathing, abrasion-resistant insulation

  • Flexible harness materials: For robotics, medical, and smart consumer devices

  • Reliable wiring harness materials: Designed for durability, safety, and traceability

Every Celestix product is tested for:

  • Electrical continuity

  • High-voltage withstand

  • Pull force

  • Cross-section crimp integrity

  • Environmental durability (temperature, abrasion, moisture)


Celestix's Commitment to Material Innovation

We invest in material innovation to meet evolving industry requirements. Our in-house engineering team develops and evaluates:

  • Heat-resistant harness insulation materials for EVs and aerospace

  • Glass wool sleeving up to 1600°C for thermal protection

  • Fiber optic wiring integration for smart harnesses

  • Celestix harness materials tracked via ERP for quality and scalability

  • In-house harness material guide to ensure supply chain transparency and compliance


Get Expert Material Selection Support

From prototype to high-volume production, Celestix offers complete transparency and control in material sourcing, validation, and testing. Fill out our quote or contact form and let our engineers recommend the most efficient, compliant, and durable solution for your next project.
